Network Analyzer Requirements

All network analyzers require Option 551 for multiport operation (N-Port error
correction and measurement capability).
network analyzer option requirements. The network analyzer's frequency range
must be equal to or exceed that of the test set so that the measurement
system covers the full frequency range of the test set.
The test set files indicated in
directory: c:\Program Files\Keysight\Network Analyzer\testsets
Table 1 Network Analyzer Configuration Requirements
4-Port
Network Analyzer
N5224/25/27A PNA
N5244/45/47A PNA-X
Ensure that the network analyzer has the latest version of firmware installed. The following web
site links provide the necessary information needed:
— Documentation - http://www.keysight.com/find/pna
— Network Analyzer Firmware -
http://na.support.keysight.com/pna/firmware/firmware.html
— U3045AM04 Test Set Files -
http://na.support.keysight.com/multiport/testsets/testset_files.html
4
Table 1
Options Test Set File
401, 551 u3045am04_pnax_p4.tsx
400, 551 u3045am04_pnax_p4.tsx
Table 1 provides a listing of other
must be installed into the analyzer's file
System Figure
Figure 1 on
page 2
Figure 1 on
page 2
Keysight U3045AM04 User's and Service Guide
