3.2. DC/AC Voltage Measurements

WARNING: Maximum input for DC V is 600, and for AC V is 600. Do not
attempt to take any voltage measurement that exceeds the limits.
Exceeding the limits could cause electric shock and damage to the
clamp meter.
3.2.1.DC Voltage
a. Set the rotary switch at V DC.
b. Insert the test leads into the input jack.
c. Connect the test prods of the test leads in PARALLEL to the circuit to
be
measured.
d. Read the measured value from the LCD display.
3.2.2. AC Voltage
a. Set the rotary switch at V AC.
b. Insert the test leads into the input jack.
c. Connect the test prods of the test leads in PARALLEL to the circuit to
be
measured.
d. Read the measured value from the LCD display.
