Configuring The Totalizer - Endress+Hauser Proline Prowirl F 200 Operating Instructions Manual

Commissioning
Parameter
Switch-off value
Switch-on delay
Switch-off delay
Assign status
Failure mode
Invert output signal
Parameter
Assign process variable
Unit totalizer
Control Totalizer
94
Description
Enter measured value for the switch-off
point.
Define delay for the switch-on of status
output.
Define delay for the switch-off of status
output.
Select device status for switch output.
Define output behavior in alarm condition.
Invert the output signal.
10.6.5

Configuring the totalizer

In the "Totalizer 1 to 3" submenu the individual totalizers can be configured.
Navigation
"Setup" menu → Advanced setup → Totalizer 1 to 3
Totalizer 1 to 3
Parameter overview with brief description
Prerequsite
–
–
In the Assign process variable
parameter one of the following
options is selected:
• Volume flow
• Mass flow
• Corrected volume flow
• Total mass flow
• Condensate mass flow
• Energy flow
• Heat flow difference
Selection / User entry
Signed floating-point number
0.0 to 100.0 s
0.0 to 100.0 s
• Low flow cut off
• Digital output 2
• Actual status
• Open
• Closed
• No
• Yes
→ Assign process variable
Unit totalizer
Control Totalizer
Totalizer operation mode
Failure mode
Description
Assignment of a process
variable to the totalizer.
Control totalizer value.
Proline Prowirl F 200 PROFIBUS PA
Factory setting
0 m³/h
0.0 s
0.0 s
Low flow cut off
Open
No
Selection Factory setting
• Volume flow Volume flow
• Mass flow
• Corrected volume
flow
• Total mass flow
• Condensate mass
flow
• Energy flow
• Heat flow
difference
Unit choose list m³
• Totalize Totalize
• Reset + hold
• Preset + hold
