Technical data
162
DN
[mm]
Order characteristic "housing," option C
Alu coated
250
300
1) For high-temperature/low-temperature version: values + 0.2 kg
Weight in US units
All values (weight) refer to devices with ASME B16.5, Class 300/Sch. 40 flanges. Weight
information in [lbs].
DN
[in]
Order characteristic "housing," option C
Aluminum-coated
½
1
1½
2
3
4
6 110.5
8 167.9
10 240.6
12 357.5
1) For high-temperature/low-temperature version: values + 0.4 lbs
Transmitter remote version
Wall-mount housing
Depends on the material of the wall-mount housing:
• Aluminum AlSi 10Mg: 2.4 kg (5.2 lb)
• Stainless steel 1.4404 (316L): 6.0 kg (13.2 lb)
Sensor remote version
Weight data:
• Including the connection housing:
– 0.8 kg (1.8 lbs)
– 2.0 kg (4.4 lbs)
• Excluding the connecting cable
• Excluding packaging material
Weight [kg]
1)
111.1
158.1
Weight [lbs]
1)
11.3
15.7
22.4
26.8
42.2
66.5
Proline Prowirl F 200 PROFIBUS PA
Order characteristic "housing," option B
1)
316L
113.8
160.8
Order characteristic "housing," option B
1)
316L
17.3
21.7
28.3
32.7
48.1
72.4
116.5
173.8
246.6
363.4
