Proline Prowirl F 200 PROFIBUS PA
Parameter
Volume flow
Corrected volume flow
Mass flow
Flow velocity
Temperature
Calculated saturated steam pressure Displays the saturated steam pressure currently calculated.
Steam quality
Total mass flow
Condensate mass flow
Energy flow
Heat flow difference
Reynolds number
Density
Pressure
Compressibility factor
Endress+Hauser
Parameter overview with brief description
Description
Displays the volume flow currently measured.
Displays the corrected volume flow currently calculated.
Displays the mass flow currently calculated.
Displays the flow velocity currently calculated.
Displays the temperature currently measured.
Displays the steam quality currently calculated.
Displays the total mass flow currently calculated.
Displays the condensate mass flow currently calculated.
Displays the calculated energy flow.
Displays the heat flow difference currently calculated.
Displays the Reynolds number currently calculated.
Displays the density currently measured.
Displays the pressure currently measured.
Displays the compression factor currently measured.
11.4.2

Totalizer

The "Totalizer" submenu contains all the parameters needed to display the current
measured values for every totalizer.
Navigation
"Diagnostics" menu → Measured values → Totalizer
Structure of the submenu
Totalizer
Temperature
Calculated saturated steam pressure
Steam quality
Total mass flow
Condensate mass flow
Energy flow
Heat flow difference
Reynolds number
Density
Pressure
Compressibility factor
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
Positive floating-point number
0 to 250 bar
0 to 2
→
Assign process variable
Operation
User interface
105
