Proline Prowirl F 200 PROFIBUS PA
Parameter
Channel
PV filter time
Fail safe type
Fail safe value
Endress+Hauser
10.5.5

Configuring the analog inputs

The Analog inputs submenu guides you systematically to the individual Analog input 1 to
4 submenu. From here you get to the parameters of the individual analog input.
Navigation
"Setup" menu → Analog inputs → Analog input 1 to 4
Structure of the submenu
Analog inputs
Parameter overview with brief description
Description
Select the process variable.
Specify a time to suppress signal peaks.
During the specified time the totalizer does
not respond to an erratic increase in the
process variable.
Select the failure mode.
Specify the value to be output when an error
occurs.
10.5.6

Configuring the local display

The Display wizard guides you systematically through all the parameters that can
configured for configuring the local display.
Navigation
"Setup" menu → Display
→ Analog input 1 to 4
Selection / User entry
• Volume flow
• Mass flow
• Corrected volume flow
• Flow velocity
• Temperature
• Calculated saturated steam
pressure
• Steam quality
• Total mass flow
• Energy flow
• Heat flow difference
Positive floating-point number
• Fail safe value
• Fallback value
• Off
Signed floating-point number
Commissioning
→ Channel
PV filter time
Fail safe type
Fail safe value
Factory setting
Volume flow
0
Off
0
75
