Proline Prowirl F 200 PROFIBUS PA
Parameter
Volume flow unit
Volume unit
Mass flow unit
Mass unit
Corrected volume flow unit
Corrected volume unit
Pressure unit
Temperature unit
Energy flow unit
Energy unit
Calorific value unit
Endress+Hauser
Parameter overview with brief description
Description
Select volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select volume unit.
Result
The selected unit is taken from: Volume
flow unit parameter
Select mass flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select mass unit.
Result
The selected unit is taken from: Mass flow
unit parameter
Select corrected volume flow unit.
Result
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Select corrected volume unit.
Result
The selected unit is taken from: Corrected
volume flow unit parameter
Select process pressure unit.
Select temperature unit.
Result
The selected unit applies for:
• Output
• Reference temperature
• Simulation process variable
Select energy flow unit.
Result
The selected unit applies for:
• Outputs
• Low flow cut off
Select energy unit.
Select calorific value unit.
Length unit
Selection
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Unit choose list
Commissioning
Factory setting
Country-specific:
• l/h
• gal/min (us)
Country-specific:
• l
• gal (us)
Country-specific:
• kg/h
• lb/min
Country-specific:
• kg
• lb
Country-specific:
• Nl/h
• Sft³/h
Country-specific:
• Nl
• Sft³
Country-specific:
• bar
• psi
Country-specific:
• °C (Celsius)
• °F (Fahrenheit)
Country-specific:
• kW
• Btu/h
Country-specific:
• kWh
• Btu
Country-specific:
• kWh/Nm³
• Btu/Sft³
