WE RECOMMEND YOU HAVE SOMEONE TO ASSIST YOU IN LIFTING AND
ASSEMBLING YOUR LIFESPAN TREADMILL. FOLLOW THESE INSTRUCTIONS
CAREFULLY AND IT WILL MAKE IT EASIER TO ASSEMBLE YOUR LIFESPAN
TREADMILL
Step 1
Remove all parts from the carton, and place the treadmill onto the floor.
Step 2
Before placing the right upright in its position, be
sure to connect the cable as pictured right. This is a
very delicate procedure and if not completed
correctly will cause the treadmill not to run
correctly and in some cases not run at all. Make
sure the pins inside the each plug line up when
connecting the two plugs (view right)
Step 3
Install the left and right uprights into the bottom
connectors. You will need 1 bracket and (7x) 8mm
bolts. The bolts and bracket are pictured (right)
exactly how they are to be attached to the upright
(view right).
Step 4
Screw in the bolts as pictured right. DO NOT
tighten the bolts fully till the display panel and
sensor meter tube are connected (view right)
