Specifications:
2-wire WIEGAND IN
2-wire WIEGAND OUT
LED IN switched against GND on WIEGAND OUT side
Open LED OUT switched against GND on WIEGAND IN side (up to 24 V / 50
mA)
5 to 16 V / 10 mA power supply from Wiegand bus receiver side
500 V DC isolation strength
Connection:
2N TELEKOMUNIKACE a.s., www.2n.cz
89/117
