2N IP Force Installation Manual page 6

®
2N IP Force is equipped with an electric lock switch. You can control the switch
using a numerical keypad or, during a call, using any telephone set. An additional
switch module can be installed if necessary. A wide range of settings allow for a
variety of applications.
®
2N IP Force can also be provided with RFID card reader modules.
®
2N IP Force is very easy to install. All you have to do is connect the system into your
LAN via a network cable and feed it from a 12 V power supply or your PoE supporting
LAN.
®
Configure 2N IP Force
®
2N Access Commander
quickly.
Advantages of Use
Uncompromising Antivandal design
High coverage level – up to class IP69K
Variable mounting options (brick/plasterboard flush mounting, surface
mounting)
Sensitive microphone and powerful loudspeaker
Bidirectional communication – acoustic echo cancelling
Integrated colour camera with wide-angle lens
Optional dial buttons including name tags and backlight
Optional numerical keypad with backlight
Integrated electronic lock switches with wide setting options
Optional integrated RFID card reader module
LAN (PoE) or external 12 V power supply
Configuration via web interface or dedicated PC application
SIP 2.0 support
Up to 1999 telephone directory positions
Up to 20 user time profiles
Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG)
Audio codecs (G.711, G.729, G.722, L16/16kHz)
HTTP server for configuration
SNTP client for time synchronisation with server
RTSP server for video streaming
SMTP client for e-mail sending
TFTP client for automatic configuration and firmware update
2N TELEKOMUNIKACE a.s., www.2n.cz
using your PC via any web browser. Use the
to manage extensive
®
2N IP Force systems easily and
6/117
