inforced/double insulation and associated testing pur-
suant to EN 50 178.
1. Transformer and optical separation in voltage
supply.
2. Optical insulation between Basic Motor Con-
trol and control card.
3. Insulation between the control card and the
power part.
4. Relay contacts and terminals relating to other
circuits on the control card.
PELV insulation of the control card is guaranteed un-
der the following conditions:
- TT network with maximum 300 Vrms be-
tween phase and earth.
VLT 2803-2875
Setup
3 x 480 V version with 1A
RFI filter
3 x 480 V version with 1A
RFI filter (R5: For IT
mains)
1 x 200 V version with 1A
1.
RFI filter
3 x 200 V version with 1A
RFI filter (R4: For use
with RCD)
3 x 480 V version with 1A
+1B RFI filter
1 x 200 V version with 1A
1.
+1B RFI filter
VLT 2880-2882
Setup
3 x 480 V version with 1B
RFI filter
1. For VLT 2822-2840 3 x 200-240 V the same values apply as for the 480 V version with 1A RFI filter.
• EN 55011: EmissionLimits and methods of measurement of radio disturbance characteristics of indus-
trial, scientific and medical (ISM) high-frequency equipment.
Class 1A:
Equipment used in an industrial environment.
Class 1B:
Equipment used in areas with a public supply network (residential, commerce and light industry).
UL Standard
84
Industrial environment
EN 55011 class 1A
Cable-borne
150 kHz- 30 MHz 30 MHz - 1 GHz
Yes
25 m screened/arm- 25 m screened/arm-
oured
Yes
5 m screened/arm- 5 m screened/arm-
oured
Yes
40 m screened/arm- 40 m screened/arm-
oured
Yes
20 m screened/arm- 20 m screened/arm-
oured
Yes
50 m screened/arm- 50 m screened/arm-
oured
Yes
100 m screened/ 100 m screened/arm-
armoured
Industrial environment
EN 55011 class 1A
Cable-borne
150 kHz- 30 MHz 30 MHz - 1 GHz
Yes
50 m
®
VLT 2800 Series
- TN network with maximum 300 Vrms be-
tween phase and earth.
- IT network with maximum 400 Vrms between
phase and earth.
In order to maintain PELV all connections made to the
control terminals must be PELV, e.g. thermistor must
be reinforced/double insulated.

EMC emission

The following system results are achieved on a system
consisting of a VLT Series 2800 with screened/arm-
oured control cable, control box with potentiometer,
screened/armoured motor cable and screened/arm-
oured brake cable as well as an LCP2 with cable.
Emission
Residential, commercial and light industry
Radiated Cable-borne
150 kHz - 30 MHz
Yes No
oured
Yes No
oured
Yes Yes
15 m screened/arm-
oured oured
Yes Yes
7 m screened/arm-
oured oured
Yes Yes
25 m screened/arm-
oured oured
Yes Yes
40 m screened/arm-
oured oured
Emission
Residential, commerce and light industry
Radiated Cable-borne
150 kHz - 30 MHz
Yes Yes
50 m 50 m
This device is UL-approved.
MG.27.A2.02 - VLT
EN 55011 class 1B
Radiated
30 MHz - 1 GHz
No
No
No
No
No
No
EN 55011 class 1B
Radiated
30 MHz - 1 GHz
No
®
is a registered Danfoss trademark
