PNU # Parameterdescription
500 Address
501 Baudrate
502 Coasting stop
503 Quick stop
504 DC brake
505 Start
506 Reversing
507 Selection of Setup
508 Selection of preset ref.
509 Bus jog 1
510 Bus jog 2
512 Telegram profile
513 Bus time interval
514 Bus time interval function
515 Data readout: Reference %
516 Data readout: Reference [unit]
517 Data readout: Feedback [unit]
518 Data readout: Frequency
519 Data readout: Frequency x scaling
520 Data readout: Motor current
521 Data readout: Torque
522 Data readout: Power [kW]
523 Data readout: Power [HP]
524 Data readout: Motor voltage [V]
525 Data readout: DC Link voltage
526 Data readout: Motor thermal load
527 Data readout: Inverter thermal load
528 Data readout: Digital input
529 Data readout: Analogue input, term. 53
531 Data readout: Analogue input, term. 60
532 Data readout: Pulse reference
533 Data readout: External reference
534 Data readout: Status word
535 Data readout: Bus feedback 1
537 Data readout: Inverter temperature
538 Data readout: Alarm word
539 Data readout: Control word
540 Data readout: Warning word
541 Data readout: Extended status word
544 Data readout: Pulse count
