Danfoss VLT 2800 Series Operating Instructions Manual page 98

PNU # Parameter description
400 Brake function
405 Reset function
406 Aut. restart time
409 Trip delay overcurrent
411 Switching frequency
412 Var. carrier frequency
413 Overmodulation function
414 Min. feedback
415 Max. feedback
416 Process units
417 Speed PID propor.ampl.
418 Speed PID intergra.
419 Speed PID differentiation time
420 Speed PID diff. amplification
limit
421 Speed PID lowpass filter
423 U1 voltage
424 F1 frequency
425 U2 voltage
426 F2 frequency
427 U3 voltage
428 F3 frequency
437 Proc. PID no/inv.
438 Proc. PID anti wind.
439 Proc. PID start frequency
440 Proc. PID start
proportional ampl.
441 Proc. PID integration time
442 Proc. PID differentiation time
443 Proc. PID diff. ampl. limit
444 Proc. PID lowpass filter time
445 Flying start
451 Speed PID feedforward factor
452 Controller range
456 Brake voltage reduce
457 Phase loss function
461 Feedback conversion
462 Enhanced sleep mode timer
463 Boost setpoint
464 Wakeup pressure
465 Minimum pump frequency
466 Maximum pump frequency
467 Minimum pump power
468 Maximum pump power
469 No flow power compensation
470 Dry run time out
471 Dry run interlock timer
484 Initial ramp
485 Fill rate
486 Filled setpoint
®
MG.27.A2.02 - VLT is a registered Danfoss trademark
VLT
Factory setting
Depends on unit type
Manual reset
5 sec.
Off (61 sec.)
4.5 kHz
No LC-filter
On
0.000
1500.000
No unit
0.010
100 ms
20.00 ms
5.0
20 ms
par. 103
Par. 104
par. 103
par. 104
par. 103
par. 104
Normal
Active
Par. 201
0.01
Off (9999.99 s)
Off (0.00 s).
5.0
0.02 s
Not possible
100%
10 %
0
Trip
Linear
Off
100%
0
20
50
0 W
0 W
1.2
Off
30 min.
Off
Off
Parameter 414
®
2800 Series
4-setup Conv.
index
No 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes -3
Yes -3
Yes 0
Yes -3
Yes -5
Yes -5
Yes -1
Yes -3
Yes -1
Yes -1
Yes -1
Yes -1
Yes -1
Yes -1
Yes 0
Yes 0
Yes -1
Yes -2
Yes -2
Yes -2
Yes -1
Yes -2
Yes 0
Yes 0
Yes -1
Yes 0
Yes 0
Data
type
5
5
5
5
6
5
5
4
4
5
6
7
7
6
6
6
6
6
6
6
6
5
5
6
6
7
6
6
6
5
6
6
5
5
97
