018 Lock for data changes
(DATA CHANGE LOCK)
Value:
Not locked (NOT LOCKED)
Locked (LOCKED)
Function:
In this parameter, it is possible to 'lock' the controls to
disable data changes via the control keys.
Description of choice:
If Locked [1] is selected, data changes in the parame-
ters cannot be made; however, it will still be possible
to make data changes via serial communication. Pa-
rameter 009-012 Display readout can be changed via
the control panel.
Operating mode at power-up, local op-
019
eration
(POWER UP ACTION)
Value:
Auto restart, use saved reference
(AUTO RESTART)
Forced stop, use saved reference
(LOCAL=STOP)
Forced stop, set ref. to 0
(LOCAL=STOP, REF=0)
Function:
Setting of the required operating mode when the mains
voltage is engaged. This function can only be active if
Local operation [1] has been selected in parameter
002 Local/remote operation.
Description of choice:
Auto restart, use saved ref. [0] is selected if the fre-
quency converter is to start using the local reference
(set in parameter 003 Local reference) and the start/
stop state given via the control keys immediately prior
to the mains voltage being cut out.
Forced stop, use saved ref. [1] is selected if the fre-
quency converter is to remain stopped when the mains
voltage is engaged, until the [START]-key is activated.
After a start command the motor speed is ramped up
to the saved reference in parameter 003 Local refer-
ence.
Forced stop, set ref. to 0 [2] is selected if the frequency
converter is to remain stopped when the mains voltage
is cut back in. Parameter 003 Local reference is to be
zeroed.
= factory setting, () = display text, [] = value for use in communication via serial communication port
16
®
VLT
NB!
In remote operation (parameter 002 Lo-
cal/remote operation) the start/stop state
at the time of mains connection will de-
[0]
pend on the external control signals. If
[1]
Pulse start [8] is selected in parameter 302
Digital input, the motor will remain stopped
after mains connection.
020 Hand operation
(HAND OPERATION)
Value:
Not active (DISABLE)
Active (ENABLE)
Function:
In this parameter you can select whether it should be
possible or not to switch between Auto- and Hand
mode. In Auto mode the frequency converter is con-
trolled by external signals whereas the frequency con-
verter in Hand mode is controlled via a local reference
directly from the control unit.
[0]
Description of choice:
[1]
If Not active [0] is selected in this parameter, the Hand
mode function will be inactive. If Active [1] is selected
[2]
you can switch between Auto- and Hand mode. For
further information, see the Control Unit section.
024 Userdefined Quick Menu
(user quickmenu)
Value:
Not active (Disable)
Active (Enable)
Function:
In this parameter you can select the standard setup of
the Quick menu key on the control panel and the LCP
2 control panel.
Using this function, in parameter 025 Quick Menu set-
up the user can select up to 20 parameters for the
Quick Menu key.
Description of choice:
If not active [0] is selected, the standard setup of the
Quick Menu key is active.
