Technical data, mains supply 3 x 380 - 480 V

According to international standards
Output current
(3 x 380-480V)
Output power (400 V)
Typical shaft output
Typical shaft output
Max. cable cross section,
motor
Input current
(3 x 380-480 V)
Max. cable cross section,
power
Max. pre-fuses
3)
Efficiency
Power loss at 100% load
Weight
4
Enclosure
According to international standards
Output current
(3 x 380-480V)
Output power (400 V)
Typical shaft output
Typical shaft output
Max. cable cross sec-
tion, motor
Input current
(3 x 380-480 V)
Max. cable cross sec-
tion, power
Max. pre-fuses
3)
Efficiency
Power loss at 100% load
Weight
4
Enclosure
1. American Wire Gauge. Max. cable cross section is
the largest cable cross section that can be attached to
the terminals. Always observe national and local reg-
ulations.
2. Type gG pre-fuses must be used for installation ac-
cording to IEC rules. If you want to maintain UL/cUL
you must use pre-fuses of the type Bussmann KTN-R
200 V, KTS-R 500 V or Ferraz Shawmut, type ATMR
(max. 30A). The fuses must be placed for protection in
a circuit that is capable of supplying a maximum of
100,000 amps RMS (symmetrical), 500 V maximum.
See table under Pre-fuses.
3. Measured using a 25 m screened/armoured motor
cable with a rated load and rated frequency.
4. IP20 is standard for VLT 2805-2875, whereas
NEMA 1 is an option.
®
MG.27.A2.02 - VLT is a registered Danfoss trademark
Type 2805 2807
I [A] 1.7 2.1
INV.
I (60s) [A] 2.7 3.3
MAX
S [KVA] 1.1 1.7
INV.
P [kW] 0.55 0.75
M,N
P [HP] 0.75 1.0
M,N
2 1) 4/10 4/10
[mm /AWG]
I [A] 1.6 1.9
L,N
I (60s)[A] 2.6 3.0
L,MAX
2 1)
4/10 4/10
[mm /AWG]
2)
20/20 20/20
IEC/UL [A]
[%] 96 96
[W] 28 38
[kg] 2.1 2.1
type IP 20 IP 20
Type 2840 2855
I [A] 9.1 12
INV.
I (60s) [A] 14.5 19.2
MAX
S [KVA] 6.3 8.3
INV.
P [kW] 4.0 5.5
M,N
P [HP] 5.0 7.5
M,N
2 1)
4/10 4/10
[mm /AWG]
I [A] 8.1 10.6
L,N
I (60s)[A] 13.0 17.0
L,MAX
2 1) 4/10 4/10
[mm /AWG]
2) 20/20 25/25
IEC/UL [A]
[%] 96 96
[W] 200 275
[kg] 3.7 6.0
type IP20 IP20
®
VLT 2800 Series
2811 2815 2822
3.0 3.7 5.2
4.8 5.9 8.3
2.0 2.6 3.6
1.1 1.5 2.2
1.5 2.0 3.0
4/10 4/10 4/10
2.6 3.2 4.7
4.2 5.1 7.5
4/10 4/10 4/10
20/20 20/20 20/20
96 96 96
55 75 110
2.1 2.1 3.7
IP 20 IP 20 IP 20
2875 2880 2881
16 24 32.0
25.6 38.4 51.2
11.1 16.6 22.2
7.5 11.0 15.0
10.0 15.0 20.0
4/10 16/6 16/6
14.9 24.0 32.0
23.8 38.4 51.2
4/10 16/6 16/6
25/25 50/50 50/50
96 97 97
372 412 562
6.0 18.5 18.5
IP20 IP20/ IP20/
NEMA 1 NEMA 1
2830
7.0
11.2
4.8
3.0
4.0
4/10
6.1
9.8
4/10
20/20
96
150
3.7
IP 20
2882
37.5
60.0
26.0
18.5
25.0
16/6
37.5
60
16/6
50/50
97
693
18.5
IP20/
NEMA 1
91
