Standard Signal Output 2 - ProMinent DULCOMETER D1C Operating Instructions Manual

Complete Operating Menu / Description

Standard signal output 2

Access to all setting menus can be blocked with an access code !
Only with 2 standard signal outputs
mA output 2
setting ?
Variable allocation
Output range
Range measured value
Range control variable
Range correction value
26
mA output 2
measured value
0...20 mA
Possible values
Initial value Increment
as per identity Measured value
code Control variable
Correction value
0...20 mA 0...20 mA
4...20 mA
3.6/4 -20 mA
Measuring range 0.01 ppm
0 %...+100 % 1 %
pH 5...9.5 pH 0.01
Control with standard signal
control
control output
positive chlor
negative dechlor
mA output 2
control output
0%
0 mA =
20 mA =
100%
Only with correction value
mA output 2
correcting value
5.00 pH
0 mA =
20 mA =
9.50 pH
Lower value Upper value
0 ppm 100 ppm
-100 % +100 %
pH -2 pH 16
mA output 2
measured value
0.00 ppm
0 mA =
20 mA =
1.00 ppm
D1C2-Cl-036-GB
Remarks
If control applicable
only with correction variable
Reduction to 3.6 mA when
alarm relay switches
(not limit-value violation)
Minimum range 0.1 ppm
Minimum range 1 %
