2. Getting started

2.1 Hardware installation

2.1.1 Preparing the physical installation

Questions
Has the incoming electrical power been taken into account ? (1)
Have the environmental specifications been taken into account ? (Room
temperature, room humidity, pollution degree, EMC environment...) (1)
Have the electrical connections cables been supplied?
(1): See 10.1 Equipment Ratings
If all the answers are YES then you can proceed with the installation.

2.1.2 Safety emergency shutdown

As described in Part 1.1.2, HCV-3048 is a high power instrument and features an
button. This button will This button will open the output of the power at the power
Stop
sockets.
WARNING
When HCV-3048 are used in parallel to increase the delivered current, it is possible to
simultaneously open the relay of the power output on all the boosters parallelized with only
one Emergency Stop
The connection can be made by using BNC T-connector on the Open In of all boosters except
the main one on which the potentiostat is connected (See 5.1.3 for more information on
connections).

2.1.3 Ventilation requirement

As our instruments are delivering power, they produce heat which needs to be evacuated to
maintain the temperature inside of the instrument as constant as possible. Precautions must
be taken to avoid blocking the air flow. Blocking the air flow will increase the temperature of
the instrument, hence reducing the lifetime of the components as well as impairing its
capabilities. All the specifications and capabilities listed in this manual are guaranteed under
recommended operation, which means normal air flow

2.1.3.1 Potentiostats/galvanostats

In all our instruments (except the vertical VSP-300) the air flows from the bottom or the front
to the back of the instrument (Fig. 9).
For the vertical VSP-300 the air flows from the right to the left when facing the instrument
(Fig. 10).
by connecting the BNCs in the back of all four instruments.
