Table 2: Description of the components of the front panel of the HCV-3048.
Item Description
1 Front fans for heat sink
To extract heat of the heat sink of the
power board. Air flow goes from front
and bottom to rear.
2 LIO (Liaison Interface Option) In
and Out (SubD15 connectors)
Used to
potentiostat/galvanostat board and to
another HCV-3048 when used in
parallel. Up to 4 boosters can be
connected in parallel, increasing the
current ability up to 120 A.
3 Status
LED Status
Off
Green
Red
Note: Exhaustive LED behavior is explained in more details in section 10.2.7.
Fig. 5: HCV-3048 front panel.
connect to the
Description
o The instrument is off line (= turned off).
o The instrument is connected to the PC and can be readily used.
o The instrument is not yet connected to the PC.
o The instrument has stopped due to a major error.
Major errors:
The Emergency Stop
-
A TTL signal is sent to the Open In BNC connector on the back
-
panel.
The AC/DC power supply of the instrument is under failure
-
status.
The instrument is overheating.
-
Manual for VMP300-based instruments
Item
4 Emergency Stop
This button can be pushed when
necessary. It will open the relays that
connect the power supply of the
instrument to the cell. The Status will
turn red.
5 Power sockets
The 6 mm banana + and – power
sockets allow to connect 10 mm
power cables
maximum current of 70 A. The
maximum voltage difference between
these two cables must be lower than
55 V.
button is pushed.
Description
2
that can pass a
