14V Booster - Bio-Logic VMP-300-based Installation And Configuration Manual

Impedance specifications (if booster board connected to board with EIS option)
Accuracy
10.2.5 4A/14V booster
Control amplifier
Compliance voltage
Compliance current
Control voltage
Operating area
For VSP-300 chassis there
is derating for the slot #5
and #6 (red curve). For all
the other case, consider the
blue curve.
Bandwidth (-3 dB)
Slew Rate (no load)
Rise/Fall time (no load)
Floating mode
Parallel ability
Current accuracy
Slew rate (no load)
Rise/Fall time (no load)
Floating mode
Parallel ability
Current accuracy
- 3 V ; +14 V
± 4 A
- 3 V ; +10 V
>4 MHz
50 V/µs
<200 nA
yes
yes
0.1% range
>50 V/µs
<200 ns
yes
Yes
0.1% range
