Hcv-3048 Used With Hv-48 Electrometer - Bio-Logic VMP-300-based Installation And Configuration Manual

Accuracy

10.2.7 HCV-3048 used with HV-48 electrometer

Control amplifier
Compliance voltage
Compliance current
Current ranges
Control voltage
User (using calibration board,
when HCV-3048 purchased
separately from pstat board)
Voltage control
Current control
Voltage measurement
Current measurement
Factory (when HCV-3048
purchased with pstat board, or
pstat board returned to factory
for calibration with HCV-3048)
Voltage control
Current control
Voltage measurement
Current measurement
Bandwidth (-3dB)
Operating area
Slew rate (no load)
Rise/Fall time (no load)
Floating mode
Parallel ability
Manual for VMP300-based instruments
[-1,50] V
± 30 A
3 (30 A, 3 A, 300 mA)
[0,48] V
Accuracy
0.1 % + 0.1 % (range + reading)
0.3 % + 0.5 % (range + reading)
0.1 % + 0.1 % (range + reading)
0.3 % + 0.5 % (range + reading)
0.03 % + 0.03 % (range + reading)
0.1 % + 0.3 % (range + reading)
0.03 % + 0.03 % (range + reading)
0.1 % + 0.3 % (range + reading)
120 kHz
Control/measurement : [-30,30] A @ [0, 48] V
(with 2.5 m cables)
20 V/µs
3 µs
Yes (350 kΩ isolation)
Yes up to 4 (120 A)
101
