Floating mode
IR compensation
Analog filtering
External input/outputs
Cell connection
Control amplifier
Compliance
Maximum current
Gain-Bandwidth compensation
Highest unity gain bandwidth
Slew rate (no load)
Rise/Fall time (no load)
Voltage control
Ranges
DC level shift
Accuracy
Lowest resolution
Current control
Ranges
Additional ranges
Accuracy
Resolution
Voltage measurement
Ranges
DC level shift
Accuracy (DC)
Maximum resolution
Bandwidth (-3 dB)
Filtering low-pass 4 poles Sallen-
Key filters
Acquisition speed
Current measurement
Ranges
Additional ranges
Accuracy (DC)
Maximum resolution
Bandwidth (-3 dB)
Filtering low-pass 4 poles Sallen-
Key filters
Acquisition speed
Electrometer
Manual for VMP300-based instruments
Yes
Yes
Yes
Yes
2, 3, 4 or 5 terminal leads (+ ground)
± 12 V
± 500 mA continuous
9 programmable stability factors
1.4 MHz
> 20 V/µs
< 500 ns
Adjustable from ± 10 V down to ± 30 mV (1 mV
resolution)
± 10 V, 300 µV resolution.
For example: For an Erange of [0;20]V, the resolution is
333.33 µV. For [0;19.66]V, the resolution is 300 µV. For
[0;13.1]V, the resolution is 200 µV. For [0; 6.55]V, the
resolution is 100 µV. For [0; 3.27]V, the resolution is 50 µV.
For [0; 1.31]V, the resolution is 20 µV. For [0; 0.65]V, the
resolution is 10 µV. For [0; 0.32]V, the resolution is 5 µV.
For [0; 0.13]V, the resolution is 2 µV. For [0; 0.06]V, the
resolution is 1 µV.
< ± 1 mV ± 0.03% of setting
1 µV
± 1 A, ± 100 mA, ± 10 mA, ± 1 mA, ± 100 µA,
± 10 µA, ± 1 µA (7 ranges + Autorange)
± 100 nA, 10 nA with gain
< ± 0.1 % of range ± 0.03 % of setting
0.0033 % of range
± 10 V, ± 5 V, ± 2.5 V, ± 250 mV, ± 25 mV
± 10 V, 300 µV resolution
< ± 1 mV, ± 0.03 % of reading
< 0.0033 % of range
8 MHz
50 kHz, 1 kHz and 5 Hz
1,000,000 samples/s
± 1 A, ± 100 mA, ± 10 mA, ± 1 mA, ± 100 µA,
± 10 µA, ± 1 µA
± 100 nA, ± 10 nA
< ± 0.1 % of range ± 0.03 % of reading
0.0033 % of range
8 MHz
50 kHz, 1 kHz and 5 Hz
1,000,000 samples/s
