10. Technical Specifications

10.1 Equipment Ratings

10.1.1 Electrical & Mechanical specifications
Instrument
type
Voltage
Range/
Vac
SP-200 [90;264]
SP-240
[90;264]
SP-300 [90;264]
VSP-300 [90;264]
VSP-300
[90;264]
(Vertical)
VMP-300 [90;264]
HCV-3048 [85-264]
* See power contour plot of HCV-3048

10.1.2 Environmental

Safety complies with EN61010-1.
EMC complies with EN61326.
RoHS complies with 2002/95/EC

10.2 Channel specifications

10.2.1 Channel board

General Functions
Potentiostat
Galvanostat
Impedance analyzer
Coulometer
Linear scan generator
94
Table 10: Instrument electrical ratings.
Input
Frequen
Power
cy
max/ Fuses
range/H
W
z
[50; 60] 350 2 x 4 AF
[50; 60] 350 2 x 4 AF
[50; 60] 350 2 x 4 AF
[50; 60] 650 2 x 5 AF
[50; 60] 650 2 x 5 AF
2 x
[50; 60] 1500
10 AF
[1700- 2 x
[47-440]
2000]* 16 AF
- Indoor use
- Operating Temperature: 10°C to +40°C Indoor use
- Storage Temperature: 0°C to +50°C
- Pollution degree: 1 (no pollution or only dry)
- Altitude: <2000 m above sea level
- Humidity: 10% to 80% non-condensing
- Case protection: IP20
- Warm-up: 1 hour to rated accuracy
- Cooling: Internal DC Fans
- Vibration: not specified
- Choke: not specified
- Noise (audible) : <60 dBa at full power
Yes
Yes
Yes (option)
Yes
Yes (option)
Manual for VMP300-based instruments
Output
a
Voltage Range/Current
10 Vdc / 500 mA
10 Vdc / 500 mA
or 14 Vdc / 4A (with 4A/14V
booster)
10 Vdc / 500 mA
or 48 Vdc/1A (with 1A/48V booster)
or 30 Vdc/2A (with 2A/30V booster)
or 14 Vdc/4A (with 4A/14V booster)
or 5 Vdc/10A (with
booster)
[0;48] Vdc / ±30 A
Mechanical
Size
(HxWxD)/mm
221x170x384
225x205x410
225x205x410
260x530x510
337x254x517
10A/5V
533x315x563
135x400x430
Weight
without
cable/kg
7.2
7.5
7.5
22
20
30
26
