IMC C SERIES User Manual page 97

5.6.1 Voltage measurement
·
Voltage: ±60 V to ±5 V
·
Voltage: ±2 V to ±50 mV without divider
An internal pre-divider is in effect in the voltage ranges ±60 V to ±5 V. In this case, the differential input
impedance is 1 MΩ, in all other ranges 10 MΩ. If the device is de-activated, the impedance is always
1 MΩ.
The inputs are DC-coupled. The differential response is achieved by means of the isolated circuiting.
configuration for voltages <5 V
5.6.2 Temperature measurement
The input channels are designed for measurement with thermocouples and PT100-sensors (RTD,
platinum resistance thermometers). Any combinations of the two sensor types can be
detailed description of temperature measurement is presented here
Temperature measurement is performed with the imc connector
alternatively be captured using two-pin thermo-connectors.
5.6.2.1 Thermocouple measurement
Please find here the DSUB-15 pin configuration
© 2018 imc Test & Measurement GmbH
with divider
The common thermocouple types make use of
linearization by characteristic curve.
The cold-junction compensation necessary for
thermocouple measurements is built into the imc
thermo-connector
Reference
.
170
CS-4108-FD, CL-4124-FD
configuration for voltages >2 V with internal divider
.
29
ACC/DSUBM-T4
(ACC/DSUBM-T4
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
97
connected.A
. Thermocouples can
32
).
32
