Bridge measurement
Parameter
Mode
Measurement modes
Input ranges
bridge supply: 10 V
bridge supply: 5 V
bridge supply: 2.5 V
bridge supply: 1 V
Bridge excitation voltage
(as an option)
Min. bridge impedance
Max. bridge impedance
Internal quarter bridge
completion
Input impedance
Gain error
Offset error
automatic shunt calibration
Cable resistance for bridges
(without return line)
© 2018 imc Test & Measurement GmbH
Value typ. min. / max.
DC
full-, half-, quarter bridge
±1000 mV/V, ±500 mV/V,
±200 mV/V, ±100 mV/V
... ±0.5 mV/V
... ±1 mV/V
... ±2 mV/V
... ±5 mV/V
10 V ±0.5%
5 V ±0.5%
(2.5 V and 1 V)
120 Ω, 10 mH full bridge
60 Ω, 10 mH half bridge
5 kΩ
120 Ω, 350 Ω
20 MΩ ±1 %
0.02% 0.05%
0.01% 0.02%
0.5 mV/V ±0.2%
<6 Ω
<12 Ω
CS-5008-FD, CL-5016-FD analog inputs
Remarks
(as an option)
(as an option)
The actual value will be dynamically
captured and compensated for in bridge
mode.
internal, switchable per software
differential, full bridge
of reading
of input range after automatic bridge
balancing
for 120 Ω and 350 Ω
10 V excitation 120 Ω
5 V excitation 120 Ω
