50 Properties of the imc C-SERIES
This can be entered directly via the scaling:
4.6.3.4 Mode (combined measurement)
Frequency
Frequency is determined by means of a
previously multiplied or divided, this can be reflected in the scaling value. The frequency is always
unsigned, for which reason there is no two-signal encoder for it.
Speed
The sequence of pulses is converted to m/s by means of a
end, the number of pulses per meter must be entered.
RPM
The sequence of pulses is converted to revolutions per minute by means of a
measurement . Toward this end, the number of pulses per revolution must be entered.
43
© 2018 imc Test & Measurement GmbH
Settings for PWM measurement in time mode
combination measurement . If the frequency was
43
combination measurement
combination
