6.10 Miscellaneous

6.10.1 Color Display
Parameter
Display
Colors
Resolution
Backlight
Contrast (typ.)
Brightness (typ.)
Connection cable
Dimensions (W x H x D)
Display area
Weight
Supply voltage
Power consumption
Temperature range
Rel. humidity
Terminal connections
Miscellaneous
Description the display
Included accessories
·
Modem cable in the extended temperature range
·
AC/DC power supply unit
·
POWER plug
© 2018 imc Test & Measurement GmbH
-20°C to +60°C
above 31°C: linear declining to 50%, according DIN EN61010-1
DSUB-9 (female) for connection to measurement device
3-pin Binder (metal) ESTO RD03 series 712, 3-pin for external current supply
anti-reflection coated glass pane to protect display
and the DSUB-9 pin configuration
86
Color Display
5.7² TFT
65536
320 x 240
LED
600:1
2
450 cd/m
RS232, max. 2 m
192 x 160 x 30 mm (w/o connectors)
approx. 11.5 x 8.6 cm
approx. 1 kg
9 V to 32 V
DC
6 V to 50 V upon request
DC
approx. 3 W with 100% back light
operating temperature
module interior temperature
80% up to 31°C,
membrane touch panel with 15 buttons
robust metal frame
.
174
