Temperature measurement - PT100
Parameter
Input range
Resolution
Measurement error
Drift
Sensor feed (PT100)
Sensor supply
Parameter
Configuration options
Output voltage
Isolation
Short-circuit protection
Accuracy of output voltage
Compensation of cable
resistances
Max. capacitive load
© 2018 imc Test & Measurement GmbH
Value typ.
min. / max.
-200°C to 850°C
-200°C to 250°C
0.063 K (1/16 K)
0.25 K
0.02%
0.1 K
0.02%
0.01 K/K
1.25 mA
Value
5 selectable settings
Voltage
Current
Power
(+1 V)
580 mA
0.6 W
(+2.5 V)
580 mA
1.5 W
+5.0 V
580 mA
2.9 W
+10 V
300 mA
3.0 W
+12 V
250 mA
3.0 W
+15 V
200 mA
3.0 W
+24 V
120 mA
2.9 W
±
190 mA
3.0 W
(
15 V)
non isolated
unlimited duration
<0.25% (typ.) / <0.5% (max.)
<0.9% (max.)
3-line control:
SENSE line as refeed
(-VB: supply ground)
>4000 µF
>1000 µF
>300 µF
CS-7008-FD, CL-7016-FD analog inputs
Remarks
4-wire measurement:
-200°C to 850°C
of reading
-200°C to 250°C
of reading
×D
D
T
T
=|T
-25°C| ambient temperature T
a
a
a
Remarks
The sensor supply module always has 5
selectable voltage settings.
default selection: +5 V to +24 V
set jointly for all eight channels
optional, special order: +12 V or +15 V can
be replaced by +2.5 V
preferred selection with 2.5 V:
+2.5 V, +5.0 V, +10 V, +12 V, +24 V
optional, special order: +15 V can be
±
replaced by
15 V. This eliminates the
internal current- and quarter bridge
measurement.
output to case (CHASSIS)
to output voltage reference ground: "-VB"
at terminals, no load
at 25°C
over entire temperature range
calculated compensation with bridges
2.5 V to 10 V
12 V, 15 V
24 V
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
151
a
