132 Technical Specs

6.2 CS-1016-FD analog inputs

Inputs, measurement modes
Parameter
Analog inputs
Measurement modes
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Sampling rate
Bandwidth
Filter (digital)
cut-off frequency
characteristic,
order
Resolution
TEDS
Characteristic curve
linearization
General
Parameter
Overvoltage protection
Input coupling
Input configuration
Input impedance
Auxiliary supply
voltage
available current
internal resistance
© 2018 imc Test & Measurement GmbH
Value
16
voltage measurement
current measurement
current feed sensors (IEPE/ICP)
Value
0 Hz to 6.6 kHz
0 Hz to 5 kHz
2 Hz to 5 kHz
16 Bit
conforming to IEEE 1451.4
Class II MMI
user defined
(max. 1023 supporting points)
Value typ. min. / max.
±
40 V
DC
differential
20 MΩ
+5 V ±5%
0.26 A 0.2 A
1.0 Ω <1.2 Ω
Remarks
ACC/DSUBM-I4
with DSUB-15 extension plug
ACC/DSUB-ICP4, not isolated
ACC/DSUBM-ICP2I-BNC, isolated
Remarks
per channel
-3 dB (analog AAF 5th order)
-0.2 dB
Butterworth, Bessel (digital)
low pass filter 8. order
Anti-aliasing filter:
Cauer 8. order with f = 0.4 f
cutoff
internal processing 24 Bit
Remarks
permanent channel to chassis
differential, >10 kΩ off-state
for IEPE/ICP-extension plug
independent of integrated sensor
supply, short-circuit protected power
per DSUB-plug
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
