146 Technical Specs
Sensor supply
Parameter
Configuration options
Output voltage
Isolation
Short-circuit protection
Accuracy of output voltage
Compensation of cable
resistances
Max. capacitive load
The description of the CS-5008-FD, CL-5016-FD.
© 2018 imc Test & Measurement GmbH
Value
5 selectable settings
Voltage Current Power
(+1 V) 580 mA 0.6 W
(+2.5 V) 580 mA 1.5 W
+5.0 V 580 mA 2.9 W
+10 V 300 mA 3.0 W
+12 V 250 mA 3.0 W
+15 V 200 mA 3.0 W
+24 V 120 mA 2.9 W
±
190 mA 3.0 W
( 15 V)
non isolated
unlimited duration
<0.25% (typ.) / <0.5% (max.)
<0.9% (max.)
3-line control:
SENSE line as refeed
(-VB: supply ground)
>4000 µF
>1000 µF
>300 µF
100
Remarks
The sensor supply module always has 5
selectable voltage settings.
default selection: +5 V to +24 V
set jointly for all eight channels
optional, special order: +12 V or +15 V can
be replaced by +2.5 V
possible ranges with 2.5 V option:
+2.5 V, +5.0 V, +10 V, +12 V, +24 V
optional, special order: +15 V can be
±
replaced by 15 V. This eliminates the
internal current- and quarter bridge
measurement.
output to case (CHASSIS)
to output voltage reference ground: "-VB"
at terminals, no load
at 25°C
over entire temperature range
calculated compensation with bridges
2.5 V to 10 V
12 V, 15 V
24 V
