6 Technical Specs

6.1 General technical Specs

Parameter
Housing type
Ingress protection
Terminal connection
Terminal connection
DI, DO, INC, DAC
Further terminal connection
Weight
Dimensions (WxHxD) in mm
Power supply
Power supply
Isolation of supply input
AC/DC adaptor
Auto start upon power up
© 2018 imc Test & Measurement GmbH
Value
alu profile
plastic portable housing
IP20
1x DSUB-15
1x DSUB-15
1x DSUB-15
1x DSUB-15
RJ45
CF-Card Slot
2x DSUB-9
DSUB-9
DSUB-9
BNC
LEMO FGG.1B.302
LEMO FGG.0B.302
LEMO FGG.0B.306
ca. 2 kg
ca. 3.5 kg
95 x 111 x 185
270 x 85 x 300
Value
10 V to 32 V DC
not-isolated
isolated
110 V to 230 V AC
configurable
General technical Specs
Remarks
CS
CL
8 digital inputs
8 digital outputs
4 counter inputs
4 analog outputs
Ethernet (100 MBit), PC/network
removable storage
two CAN FD nodes
external display (CS)
external GPS module
synchronization
supply CL
supply CS
REMOTE
CS
CL
CS
CL
Remarks
CS
CL
external adaptor included in delivery
automatic start of measurement
