IMC C SERIES User Manual page 161

Measurement with ICP
Parameter
Max. input voltage
Input impedance
High-pass cutoff frequency
imc CRONOScompact (CRC), C-SERIES
UNI2-8, DCB2-8, LV3-8
imc CRONOSflex (CRFX):
UNI2-8, DCB2-8, LV3-8
All further channel types:
Amp input impedance:
20 MΩ
10 MΩ
1 MΩ
Constant current feed
Voltage swing
Current source impedance
1 Resulting impedance of 10 MΩ (ICP plug) and amplifier input impedance (depending on selected range)
2
Resulting cut-off frequency of combined analog and digital high pass (depending on input impedance / selected range)
Digital high pass for complete removal of residual offset: supported for selected amplifier types
3 The specifications apply to the extension plug as of version 3, delivery date from October 2017.
Find here the description of the ACC/DSUBM-ICP2I-BNC.
Common mode rejection ratio (CMRR)
(in conjunction with amplifier UNI2-8, range 10 mV, with digital high pass activated)
This typical plot refers to extension plug version 3
system software. That will result in activation of a digital high pass, in addition to the usual analog input
high pass (AC coupling of signals with 12 V DC offset). Such firmware driven signal processing will remove
any remaining residual offsets.
© 2018 imc Test & Measurement GmbH
TM
-, DELTATRON®-, PIEZOTRON®-sensors
Value typ.
0.5 MΩ
6.6 MΩ
0.40 Hz
0.12 Hz
0.10 Hz
0.14 Hz
0.75 Hz
4.2 mA
24 V
340 kΩ
min. / max. Remarks
<±40 V at BNC input
>490 kΩ depending on input range of the
measurement inputs used
>5 MΩ
-3 dB, depending on selected input
2, 3
range
including digital high pass
including digital high pass
no digital high pass applied
±10%
>22 V
>100 kΩ in parallel with input impedance of the
amplifier
56
3
and assumes that the plug is recognized by the
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
Miscellaneous 161
