IMC C SERIES User Manual page 164

164 Technical Specs
6.10.7 SUPPLY Sensor supply module
Parameter
Configuration options
Output voltage
Isolation
Standard:
option, upon request:
Short-circuit protection
Accuracy of output voltage
Efficiency
Max. capacitive load
The description of the sensor supply.
© 2018 imc Test & Measurement GmbH
Value (typ./ max.)
5 adjustable ranges
Voltage Current Netpower
(+2.5 V) 580 mA 1.5 W
+5.0 V 580 mA 2.9 W
+10 V 300 mA 3.0 W
+12 V 250 mA 3.0 W
+15 V 200 mA 3.0 W
+24 V 120 mA 2.9 W
±
190 mA 3.0 W
( 15 V)
non isolated
isolated
unlimited duration
<0.25% (typ.)
<0.5% (max.)
<0.9% (max ).
typ. 72%
typ. 66%
typ. 55%
typ. 50%
>4000 µF
>1000 µF
>300 µF
77
Remarks
The sensor supply module always got 5
selectable voltage ranges.
Default ranges: +5 V to +24 V
special order, +12 V can be replaced by +2,5 V
set globally for all channels of an amplifier.
special order, +15 V can be replaced by
output to case (CHASSIS)
nominal rating: 50 V, Test voltage (10 sec.): 300
V, not available with option ±15 V.
to output voltage reference ground
at terminals, no load
25°C
25°C
over entire temperature range
10 V to 24 V none isolated
5 V
10 V to 24 V isolated
5 V
2.5 V to 10 V
12 V, 15 V
24 V
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
±
15 V
