5.2.3 LEDs and BEEPER
6 Status LEDs and a beeper are provided as additional visual and acoustic "output channels". They can be
used just as standard output channels in imc Online FAMOS by assigning them the binary values "0" / "1"
or functions taking the Boolean value range. Interactive setting and Bit-window display for these output
channels is neither especially useful nor supported. It is not possible to deactivate the beeper by
software. The beeper indicates the starting buffering period of the UPS.
5.2.4 SYNC
For a synchronized measurement use the SYNC terminal. That connector has to be connected with other
imc devices or a DCF77 antenna.
·
When using multiple devices connected via the Sync terminal for synchronization purposes, ensure
that all devices are the same voltage level. Any potential differences among devices may have to be
evened out using an additional line having adequate cross section. Alternatively it is possible to
isolate the devices by using the module ISOSYNC.
·
If the SYNC plug at your device is marked with a yellow ring surrounding the BNC connector it is
already isolated and it is protected against potential differences.
·
See also chapter Synchronization in the imc software manual.
Technical details: synchronization
