6.6 CS-5008-FD, CL-5016-FD analog inputs

Channels, measurement modes, terminal connection
Parameter
Inputs
Measurement modes
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Sampling rate
Bandwidth
Filter (digital)
cut-off frequency
characteristic
order
Resolution
TEDS
Characteristic curve
linearization
General
Parameter
Overvoltage protection
Input coupling
Input configuration
Input impedance
Auxiliary supply
voltage
available current
internal resistance
© 2018 imc Test & Measurement GmbH
Value
8
16
voltage measurement
current measurement
bridge sensor
strain gauges
current-fed sensors (IEPE/ICP)
Value
£
100 kHz
0 Hz to 5 kHz
1 Hz to 2 kHz
16 Bit
conforming IEEE 1451.4 Class II MMI ACC/DSUBM-TEDS-xx
user defined
(max. 1023 supporting points)
Value typ. min. / max.
±40 V
DC
differential
20 MΩ ±1%
+5 V ±5%
0.26 A 0.2 A
1.0 Ω <1.2 Ω
CS-4108-FD, CL-4124-FD analog inputs
Remarks
CS
CL
ACC/DSUBM-I2 shunt-plug or
Single-ended (internal shunt)
ACC/DSUBM-B2
full, half, quarter bridge
with DSUB-15 extension plug:
ACC/DSUBM-ICP2I-BNC, isolated
Remarks
per channel
-3 dB
Butterworth, Bessel (digital)
low pass or high pass filter 8th order
band pass, LP 4th and HP 4th order
Anti-aliasing filter: Cauer 8.order
with f = 0.4 f
cutoff s
internal processing 24 Bit
Remarks
permanent
only with DSUB-15 variant
for IEPE/ICP extension plug
independent of integrated
sensor supply, short-circuit protected
power per DSUB-plug
