Basic cabling
240 VAC mains feed to external door and lock control power supply (EVBPS)
240 VAC mains feed to each handset (via transformer- supplied)
4 core from each external call station (front/rear) to its own power supply (EVBPS)
CAT5e from each external call station (front/rear) to each handset
4 core from push to exit button to EVBPS (power supply)
4 core from lock to EVBPS (power supply)
4 core from EVBPS (power supply) to emergency break glass (if fitted)
2 pairs of CAT5e from supplied power supply to each handset
Note: The maximum cable distance from the external panel to each internal handset
is 100 meters using CAT5e cable. The maximum distance per supplied power
supply to each handset is 10 meters using 2 pairs of CAT5e cable.
