Planning and installing the Enterview VX

External call station
How many Entry Doors (Front or/and Rear)
Mounting: flush or surface.
Equipment required
External call station (one required per door)
Maximum of 4 call buttons
External call station power supply DC 12 volts (EVBPS) (one required per door)
Handset EV5H/EV5HF (minimum of one per external call button)
The maximum distance per supplied power supply to each handset is 10 meters
using 2 pairs of CAT5e cable.
Electric lock magnetic (ML250)/Yale type (ENTERD)
CAT5e cable minimum 4 cores (see Note above regarding cable distances)
Push to exit button (one required per door if magnetic lock used)
Emergency break glass (One required per door if magnetic lock used and the door
is deemed and emergency exit)
Combined timed lock and outdoor call station power supply (EVBPS)
Note: The maximum cable distance from the external panel to each internal handset
is 100 meters using CAT5e cable.
Handsets
Audio/video handsets: a minimum of one per external call button/ a maximum of
4 video door entry handsets and 2 audio only handsets.
Each handset requires the supplied power supply.
Door Gear
Power supply with timed output (EVBPS)
Magnetic lock or Yale type lock
Push to exit button and emergency break glass (only needed when magnetic lock
fitted and to an emergency exit door)
3
