  • Page 1 AUDIO DOOR ENTRY SYSTEMS...

  • Page 2: Table Of Contents

    Evoke Call Point and Evoke Handset Wiring ....... . .

  • Page 3: Product Descriptions And Technical Specifications

    Calling Button Extension call transferring Keypad Unlock Calling Button Evoke KP Call Point Evoke Call Point Clear 2-way audio (Requires 12 VDC PSU - EVBPS) Single call button Keypad door access Weather shield Up to 30 programmable pin codes Metal finish...

  • Page 4: Evoke Call Point And Evoke Handset Installation

    Evoke Call Point Installation 1. Distance of each fixing screws as shown below. Mark fixing screw positions and cable entry hole. 2. Drill fixing and cable entry holes and mount steel wall plate. Connect incoming cable to the red/black on camera.

  • Page 5: Evoke Call Point And Evoke Handset Wiring

    N.O = Yale N.C = Mag Lock LOCK From Handset + Push to Exit Button - EVEXIT Evoke Handset to Evoke Call Point Wiring Evoke Handset with Evoke Call Point Handset 1 Handset 1 Lock selector switch N.O = Yale 240V AC N.C = Mag Lock...

  • Page 6: Evoke Kp Call Point And Evoke Handset Installation

    Evoke KP Call Point Installation (Requires 12 VDC PSU - EVBPS) Water cover 1. Select a suitable location to mount the outside door station. Mark the fixing and cable entry holes, the shroud can be used as a template for this.

  • Page 7: Evoke Kp Call Point And Evoke Handset Wiring

    Evoke KP Call Point System Wiring Evoke Handset(s) with Keypad Additional accessories required for door control 240V AC 4 Core 2 Core EV-BPS 2 Core 4 Core 2 Core 2 Core 2 Core EV-EBG 2 Core 2 Core EV-ML250 240 AC...

  • Page 8: Operating Evoke / Evoke Kp

    Operating Evoke / Evoke KP Delete user PIN numbers 1. Enter the programming mode first. Calling: 2. Enter the allocation number you want to Press the call button to call the indoor monitor. delete from 01 - 40. The speaker of the indoor monitor sounds and 3.
