COMMUNICA TION
8.14
FIRST IP PORT
8.15
SECOND IP ADDR
000.000.000.000
8.16
SECOND IP PORT
8.17
RECEIVER 2 PROG
8.18
ALARM
8.19
SPV/TRBL
8.20
O/C USER
8.21
TEST RPT
MESSAGING SETUP
9.1
MESSAGING SETUP
9.2
ENABLE MESSAGING
Digital Monitoring Products
16
First IP Port
Enter the first IP port number to be used in conjunction with the First IP Address. The IP
2001
port identifies the port used to communicate messages to and from the communicator.
The default IP Port setting is 2001.
Second IP Address
Enter the second IP address where the communicator sends network messages. The IP
Address must be unique and cannot be duplicated on the network. Enter all 12 digits and
leave out the periods. For example, enter IP address 192.168.0.250 as 192168000250.
The periods display automatically.
Second IP Port
Enter the second IP port number to be used in conjunction with the Second IP Address.
2001
The IP port identifies the port used to communicate messages to and from the
communicator. The default IP Port setting is 2001.
Receiver 2 Programming
Allows you to set the options for the second receiver the communicator attempts to
contact when sending reports. The communicator supports communication to two
receivers. If you select YES for any of the Receiver 2 options, you must have at least one
IP address programmed in Receiver 2 programming. Receiver 2 defaults are set to NO.
Alarm Reports
NO YES
YES enables Abort, Alarm, Alarm Restoral, Alarm Bell Silenced, Ambush, Exit Error, and
System Recently Armed reports to be sent to this receiver. Default is NO.
Supervisory/Trouble Reports
NO YES
YES enables Supervisory, Trouble, Trouble Restoral, Force Armed, Late to Close, and
Fault reports to be sent to this receiver. Default is NO.
Opening/Closing and User Reports
NO YES
YES enables Opening/Closing, Door Access, Schedule and Code Changes, Bypass, and
Sensor Reset reports by user to be sent to this receiver. Default is NO.
Test Report
NO YES
YES enables the Recall Test report to be sent to this receiver. Default is NO.
Messaging Setup
This section allows you to enter the information needed to send and receive messages
directly to and from the panel via E-Mail and MyAccess™ text messaging using CDMA
cellular communication. All of the name and password options below allow up to 32
lowercase characters to be entered. The Destination addresses allow up to 48 characters
to be entered. System Name is displayed with initial caps.
The transmitted messages are:
• Zone Alarms by Zone Name
• Zone Troubles by Zone Name
• Zone Bypass by User
• Arming (Closings) by User
• Disarming (Openings) by User
• Late to Close
• Late to Open
• Early to Close
• AC Power Trouble and Restoral
• System Low Battery
• Ambush
• Abort, Cancel and Alarm Verified by User
• Check-in by User
Enable Messaging
Select YES to allow the panel to send messages to three programmed destinations.
NO YES
Default is NO.
Messaging Setup
CellComSL Series Communicator Install/Programming Guide
