PROGRAMMING INTRODUCTION

Programming the CellComSL Series Cellular Alarm Communicator

6.1

Before You Begin

Before starting to program, we recommend you read through the contents of this manual. The information in
this document allows you to quickly learn the programming options and operational capabilities of the CellComSL
Series Cellular Alarm Communicator.
After this Introduction, the remaining sections describe the functions of each programming menu items along with
their available options. The communicator contains all of its programming information in an on-board processor
and does not require an external programmer.
In addition to this manual, you should also be familiar with the following documents:
CellComSL Series Cellular Alarm Communicator User Sheet
CellComSL Series Cellular Alarm Communicator Programming Sheet

Programming Information Sheet

Included with each communicator are the Programming Sheets. These sheets list the various options available for
programming the communicator. Before starting, completely fill out the sheets with the programming options you
intend to enter into the communicator.
Having completed programming sheets available while entering data helps to prevent errors and can shorten
the length of time you spend programming. Completed sheets also provide you with an accurate account of the
communicator's program you can keep on file for future system service or expansion.
The remainder of the Introduction explains starting and ending a programming session.
6.2

Getting Started

Ground Yourself Before Handling the Panel! Touch any grounded metal before touching the communicator
to discharge static.
Remove All Power From the Panel! Remove all AC and Battery power from the communicator before
installing or connecting any wires to the communicator.
The communicator should be completely installed before you begin programming. Make sure the communicator is
properly grounded, and the AC and battery wires are correctly installed.

Initializing the CellComSL Series

When programming a communicator for the first time or rewriting the entire program of an existing communicator,
use the Initialization function described in section 7. Initializing clears the communicator's memory of any old
data and sets the highest numbered user number to user code 99.

Accessing the Programmer

To access the programmer function of the communicator:
1. Connect the keypad to the PROG header
2. Press the reset button.
3. Enter the code 6653 (PROG).
4. The keypad displays: PROGRAMMER.
6.3

Programming Menu

You are now ready to start programming the CellComSL Series Cellular Alarm Communicator. Pressing the
COMMAND key scrolls you through the programming menu items listed below.
Menu Item
Initialization
Communication
Messaging Setup
Remote Options
System Reports
System Options
To select a section for programming, press any Select key/area when the name of that section displays on the
keypad. The detailed instructions for each programming step are found in this manual.
CellComSL Series Communicator Install/Programming Guide
Section in This Manual
7
8
9
10
11
12
Menu Item
Section in This Manual
Output Options
Area Information
Zone Information
Stop
Set Lockout Code
13
14
15
16
17
Digital Monitoring Products
11
