Unit Parts - Circutor Getest Instruction Manual

Wiring
When using a rolled extension cord to connect the unit to the mains, it is necessary to
unroll it completely to perform the test, as well as the current and voltage coils
supplied with the unit.

6.2.- UNIT PARTS

GETEST
Power on
indicator
Measurement
connection
Current injection
connection
Max R 5A Max R 10A
Safety switch
Bluetooth
connection
indicator
Page 13 of 24
Max R 25A
20 A D-curve circuit
breaker
Power supply
connector IEC C20
GETEST
Max R 50A
