Type
Input impedance
Resolution
Maximum current
Ranges
Accuracy
Range
Accuracy
Communications
UART protocol, key protected, on Bluetooth v1.2
Class I
TX Power: +18 dBm
Sensitivity: -88 dBm
Regulatory approvals:
FCC Part 15 Subpart C Section 15.247
ETSI EN 300 328
ETSI EN 301 489-1
ETSI EN 301 489-17
EN61000-3-2, EN61000-3-3
EMC Compliance
The device complies with EU directives LVD 2006/95/EC and EMC 89/336/EEC.
Due to the nature of the device, an injection of several amps will cause some disturbances in the
power supply lines, but the EMC directive permits these disturbances in these cases, in which the
phenomenon is inherent to the nature of the device.
Furthermore, depending on the quality of the power supply lines, the power supply voltage may
drop to 20% for 20 ms, so we recommend disconnecting all units that are sensitive to these line
variations before taking measurements
Category
IEC61010 CAT III 600V
Power supply
Current injection
Voltage measurement
Ammeter
100 Vac range – 0.1 Vac resolution
10 Vac range – 0.1 Vac resolution
2% reading + 2 digits
Measuring resistance
2.5% reading + 2 digits
Connections
4 mm safety jack CATIV 600V 32 A
4 mm safety jack CATIV 600V 32 A
Page 11 of 24
True-RMS
Less than 0.1 Ω
100 Aac
Auto (10, 100)
0- 120 Ω
IEC320 C20 16A
