EVAL-ADHV4702-1CPZ

ORDERING INFORMATION

BILL OF MATERIALS

Table 1. Bill of Materials
Item Qty. Reference Designator
1 1 Not applicable
2 1 A1
3 2 C1, C2
4 2 C8, C10
5 1 C11
6 1 C12
7 1 C13
8 6 C14, C15, C16, C17, C18, C19
9 1 C20
10 5 C3, C4, C5, C6, C7
11 1 CFB
12 1 D1
13 1 D2
14 3 D3, D4, D5
15 2 D6, D7
16 1 DS1
17 2 GND, GND1
18 2 INN, INP
19 3 INN1, INP1, VOUT
20 6 INN_TP, INN_TP1, INP_TP,
INP_TP1, OUT, TMP
21 3 P1, P4, SDN
22 3 P2, P3, P5
23 1 P6
24 1 PWR
25 2 R1, R2
26 2 R11, R12
27 1 R13
28 1 R14
29 1 R15
30 1 R16
31 4 R17, R18, R21, R22
32 2 R19, R20
33 1 R25
34 5 R26, R27, R28, R30, RADJ
35 1 R29
36 1 R3
37 1 R5
38 3 R6, R7, RINP
39 1 RFB
40 1 RG
User Guide
Description
EVAL-ADHV4702-1CPZ evaluation
board
ADHV4702-1
Ceramic capacitor, X7R, C2225H61,
250 V
Ceramic capacitor, X5R, C1210, 25 V
Ceramic capacitor, C0805, 100 V
Ceramic capacitor, X7R, C0805H53,
50 V
Ceramic capacitor, NP0, C0805, 50 V
Ceramic capacitor, X7R, C1210,
220 V
Capacitor, tantalum, C3528, 16 V
Ceramic capacitor, X7R, 1210, 250 V
Ceramic capacitor, C0603, 250 V
Diode, Zener, SOT-23, 5.6 V
Diode, DO-214AC
Diode, SOD123F, 600 V
Diode, SOT-23, 70 V
LED
Connector, test point
Connector, SMB
Connector, SMA end launch
Connector, test points
Connector, PCB, Berg, header,
straight, male, 3-position
Connector, PCB, Berg, header,
straight, male, 2-position
Connector, PCB dc power jack
Connector, PCB, header, right angle
Resistor, 2512, 1%, 500 V
Resistor, 1206, 0.1%
Resistor, 0805, 1%
Resistor, 0805, 1%
Resistor, 0805, 1%
Resistor, 1206, 1%
Resistor, 1206, 1%
Resistor, 1206, 1%
Resistor, 1210, 0.1%
Resistor, 0603, 1%, 50 V
Resistor, 0603, 1%, 50 V
Resistor, 1206
Resistor, 1206
Resistor, 1210, 200 V
Resistor, 1206, 1%
Resistor, 1206, 1%
Rev. 0 | Page 7 of 10
Manufacturer Part Number
Analog Devices 08_044831c
Analog Devices ADHV4702-1BCPZ
Kemet C2225C125KARACTU
Murata GRM32ER61E226KE15L
AVX 08051A100JAT2A
Murata GRM21BR71H105KA12B
Yageo CC0805JRNP09BN271
AVX Corporation 12102C224KAT2A
AVX Corporation TCNL476M016R0250
TDK C3225X7R2E104K
Murata GQM1875C2E2R0BB12
On Semiconductor BZX84C5V6LT1/T3G
Littelfuse SMAJ70A
Central CMMR1U-06 TR LEAD
Semiconductor FREE
On Semiconductor BAV199LT1G
Rohm SML-D12P8WT86
Components TP-104-01-00
Corporation
Amphenol 142134
Cinch Connectivity 142-0701-801
Solutions
Keystone Electronics 5015
Samtec TSW-103-08-G-S
Amphenol FCI 69157-102HLF
Kycon KLDX-SMT2-0202-ATR
MOLEX 22-12-2034
VISHAY CRCW251249R9FKEG
Susumu Co, LTD RG3216P-4992-B-T5
PANASONIC ERJ-6ENF1002V
ROHM MCR10EZHF5103
PANASONIC ERJ-6ENF1272V
BOURNS CRS1206-FX-1000ELF
PANASONIC ERJ-8ENF2000V
PANASONIC ERJ-8ENF2003V
PANASONIC ERA-14EB103U
Multicomp (SPC) MC0603WG00000T5E-TC
Panasonic ERJ-3EKF2401V
Vishay CRCW12060000Z0EAHP
Panasonic ERJ-8GEY0R00V
Vishay CRCW12100000Z0EAHP
Panasonic ERJ-8ENF3922V
Panasonic ERJ-8ENF2001V
UG-1444
