Network Communication Setup

Network setup is essential prior to configuration. Use the flowchart as a guide to setting up
the control processor for network use.
Figure 5.
Network Communication Setup
Connect the control processor
and PC to the same network.
Apply power to all devices.
Open the Toolbelt software from within
Global Con gurator (GC Professional or GC Plus mode)
or as the stand-alone application.
Start Device Discovery.
Toolbelt displays a list of all Extron control devices
connected to the network.
Using the MAC address, locate the desired device
in the list and select it.
Use the Set IP feature in Toolbelt or
use the Toolbelt Manage > Network Settings tab
feature to enter the IP address, subnet address,
and gateway, then con gure other network settings
as needed.
