IPL Pro Series Control Processor Reset Mode Summary
Use This Activation
Mode to...
Toggle stop/ To stop or start a program:
start program
1. Hold down the Reset button for about 3 seconds, until the
Power LED blinks once.
2. Release and press the Reset button momentarily (for
<1 second) within 1 second*.
* Nothing happens if the momentary press does not occur
within 1 second.
NOTE: This reset mode is supported on firmware version 2.00.0002-b004 and higher.
Enable or To enable or disable the DHCP client:
disable the
1. Press the Reset button five times (consecutively).
DHCP client
2. Release the button. Do not press the button within 3 seconds
following the fifth press.
NOTES:
DHCP toggle mode is supported on firmware version 3.0 or higher.
•
By default DHCP is off and the unit uses a static IP address.
•
When you disable DHCP, the unit reverts to using the previously-set static IP address.
•
Reset IP To reset all IP settings:
settings and
1. Hold down the Reset button for about 6 seconds until
port maps
the Power LED blinks twice (once at 3 seconds, again at
to factory
6 seconds).
defaults
2. Release and press the Reset button momentarily (for
without
<1 second) within 1 second*.
affecting user-
* Nothing happens if the momentary press does not occur
loaded files
within 1 second.
Start over with To reset the unit to all factory default settings:
configuration
1.
Hold down the Reset button for about 9 seconds until the
and uploading
Power LED blinks three times (once at 3 seconds, again at
6 seconds, again at 9 seconds).
2. Release and press the Reset button momentarily (for
<1 second) within 1 second*.
* Nothing happens if the momentary press does not occur
within 1 second.
NOTE: After performing a Reset All IP Settings or Reset to Factory Defaults reset, set
the IP address again (by using Toolbelt) for use on your network.
Result
The LED blinks 2 times if the program is
•
starting.
The LED blinks 3 times if the program is
•
stopping.
The Reset LED blinks 6 times if the DHCP
•
client is enabled.
The Reset LED blinks 3 times if the DHCP
•
client is disabled.
Reset All IP Settings mode:
Sets the IP address back to factory default
•
(192.168.254.250)
Sets the subnet back to factory default
•
(255.255.255.0)
Sets the default gateway address to the
•
factory default (0.0.0.0)
Sets domain and host names to factory
•
default
Sets port mapping back to factory default
•
Turns DHCP off
•
Turns events (user-created schedules,
•
macros) off
Stops any running program.
•
Reset to Factory Defaults mode performs a
complete reset to factory defaults (except the
firmware).
Does everything Reset All IP Settings mode
•
does
Removes (clears) all user-loaded files and
•
configurations from the control processor:
Clears driver-port associations (IR,
•
serial, Ethernet) and port configurations
Removes button/touchpanel
•
configurations
Removes schedules, settings, macros
•
