Design and function
Wire feed
5.11.5 Spool brake setting
Item Symbol
1
•
Tighten the Allen screw (8 mm) in the clockwise direction to increase the braking effect.
Tighten the spool brake until the wire spool no longer turns when the wire feed motor stops but
without it jamming during operation!
42
Description
0
Allen screw
Securing the wire spool retainer and adjustment of the spool brake
Figure 5-15
099-000236-EW501
21.10.2015
