Intended use

3
Hazards due to improper usage!
Hazards may arise for persons, animals and material objects if the equipment is not
used correctly. No liability is accepted for any damages arising from improper usage!
•
The equipment must only be used in line with proper usage and by trained or expert staff!
•
Do not modify or convert the equipment improperly!
3.1

Applications

3.1.1

TIG hot wire welding

The TIG hot wire welding system technology is based on the TIG cold wire welding system technology.
A wire feed system transports the wire-like welding consumable, which is heated at the stick-out between
contact tip and weld pool contact point by means of resistance heating. A second power source is
required for this resistance heating. Its secondary power circuit is closed by the wire's permanent contact
with the weld pool. The process of pre-heating the wire can be controlled in a wide range by the selected
hot wire power.
By pre-heating the wire, the energy taken from the weld pool for melting the wire can be reduced. This
allows a significantly larger amount of welding consumables to be used at a higher welding speed, thus
reducing the energy per unit length.
3.1.2

TIG cold wire welding

Cold wire welding is a variant of TIG welding featuring mechanically fed filler material. With this process,
cold welding wire is melted, without power, in the arc of a tungsten electrode.
3.2

Use and operation solely with the following machines

A suitable power source (system component) is required in order to operate the wire feed unit!
A cold/hot wire Tetrix power source (AW) is required for operation.
099-000236-EW501
21.10.2015
WARNING
Intended use
Applications
13
