5.11.3 Changing the wire feed rollers

Unsatisfactory welding results due to faulty wire feeding! Wire feed rollers must be suitable for
the diameter of the wire and the material.
•
Check the roller label to verify that the rollers are suitable for the wire diameter.
Turn or change if necessary!
•
use V-groove rollers with for steel wires and other hard wires,
•
use U-groove rollers for aluminium wires and other soft, alloyed wires.
•
Slide new drive rollers into place so that the diameter of the wire used is visible on the drive roller.
•
Screw the drive rollers in place with knurled screws.
099-000236-EW501
21.10.2015
Design and function
Figure 5-13
Wire feed
