8.2.2.3 PC Application
®
This sub-section contains options regarding the relevant IP address connection to the iNetVu
7700 Series Central Controller. This section allows user to enter IP address of the desired
controller that they wish to connect to over the network.
ACU (Antenna Control Unit) IP Address
User can enter IP address of a networked controller and connect to it over the Network.
Com Port
Used in conjunction with the serial port interface (Interface parameter under COM Port
Configuration section) communication between the controller and pc.
Log Data
The user may choose to upload either 1 hour, 2 hours, or ALL (maximum of 12 hours) of the
recorded data log information from the controller to the PC. The log file is saved in the default
installation location as "iNetVu7710Data_history"
