4 - AZ Search Window Status
The Search Window is the area of the sky which the iNetVu
desired Satellite. It uses a rectangular window and searches for the Satellite using smaller
concentric windows until the desired Satellite is found.
7.7.7.
S1
This menu displays the Target Satellite Number and Longitude, Target Antenna Coordinates,
DVB Transponder (Frequency, Symbol Rate, and Code Rate) and LNB Power.
1
4
5
Target satellite Beam number
1 -
Target Satellite Longitude and Hemisphere
2 -
Target Satellite Antenna Elevation, Azimuth (within reference to true north), and Polarization
3 -
coordinates respectively
4 - Transponder Number
(There are usually six (6) transponders for each satellite stored into the controller memory) 0 – 2 are
horizontal Receive, and 3-5 are vertical receive) the user may overwrite the transponder data with
his/her own (see configuration section).
5 - DVB Transponder Frequency (KHz)
6 – Transponder Symbol Rate (sps)
7 –Transponder Code Rate.
DB-1 = 1/2
DB-2 = 2/3
DB-3 = 3/4
DB-5 = 5/6
DB-7 = 7/8
AUTO (DVB-S1 or DVB-S2A SELECTION)
8 – Power Supplied to LNB from the Controller for the Target Satellite
2
1_115W E24 A0 P0
3 0990 30000
"S1" (Target Satellite) Display
Fig. 23:
iNetVu™ 7710 Controller User Manual
® Mobile System will search for the
3
8
DB-7 18
7
6
