SAT (BEAM)

6
7
1 – Target Satellite Beam ID
2 – Target longitude and Hemisphere
3 – Transponder number Horizontal Receive (0-2), Vertical Receive (3-5)
4 – Modem Beam ID
5 – Read Carrier From Modem (iDirect & Hughes Ku Only)
– Enabled
Y
– Disabled
N
6 – Inclined Satellite Search
Enabling this option will allow the system to maintain signal with an inclined orbital satellite. The
user may select the time difference between each re-peak on the inclined orbital satellite without
disabling the transmitter and maximizing on the signal strength. If signal strength drops before the
re-peaking time is due, the system will automatically re-peak to maintain signal strength. Feature
enhanced and will be used with regular Ku/Ka services to maintain strong signal when platform
shifts or swings in position. The Inclined Satellite option will ignore Motion Detection if it's enabled
at the same time; the Inclined Satellite Search feature has a higher priority than the Motion
Detection and thus will render it ineffectual.
DIS: Disabled
1: Re-peak every 10 minutes
2: Re-peak every 30 minutes
3: Re-peak every 1 hours
4: Re-peak every 2 hours
5: Re-peak every 3 hours
6: Re-peak every 4 hours
7: Re-peak every 6 hours
8: Re-peak every 8 hours
9: Re-peak every 12 hours
7 – Reference Satellite
D – The user should select "D" to disable this option.
E – If the user wishes to use the reference satellite, "E" should be selected.
3
2
1
05 009.0E - 0 MBM059 Y
IN:D REF:D BM01_072W
Fig. 31: Beam and orbital Configuration
